Helio Spark

Name: Helio Spark
Brand: Helio Cure
SKU: heliocure-spark
Price: 399.0 USD
Availability: InStock
Rating: 4.99 (162 reviews)

The Helio Spark is a clinical-grade red light therapy panel with the industry's highest density of the deepest healing wavelengths. From 630 nm at the skin's surface to 1064 nm, the wavelength used in brain research, reaching up to 5 centimeters into muscle, joint, and deep tissue. Small enough to travel, strong enough for daily therapy.

72 LEDs measuring above 300 mW/cm² at source. Independently tested by LightLab International. FDA-registered Class II medical device.

Face & Skin
Pain & Inflammation
Weight Loss
Brain Health
Hair Growth
Total Wellness

$399.00; $399.00; ~~$599.00~~
Unit price: per

Choose your coverage

Targeted Areas72 LEDsHelio Spark $399Larger Areas216 LEDsHelio Glow $999 Full Length480 LEDsHelio Blaze $2,799 Complete Coverage864 LEDsHelio Nova $4,999

Quantity:

Subtotal: $399.00

60-Day Risk-Free Trial
3-Year Warranty
Free U.S. Shipping

Try it at home for 60 days

Live with it for 60 days. If it doesn't change how you feel, send it back. No questions, no restocking fee. Return Policy →

Helio Spark Specifications

Wavelengths & Density

Total Wavelength Bands: 6
Spectral Range:
- Red Spectrum: 630 nm and 660 nm
- Lower Near-Infrared (NIR): 810 nm and 830 nm
- Mid Near-Infrared (NIR): 850 nm
- Deep Near-Infrared (deep NIR): 1064 nm
LED Density: 38.88% red, 41.66% NIR, and 19.44% deep NIR
- 630 nm: 19.44%
- 660 nm: 19.44%
- 810 nm: 19.44%
- 830 nm: 13.88%
- 850 nm: 8.33%
- 1064 nm: 19.44%
Channel Mapping:
- Channel 1: Red (630 + 660 nm)
- Channel 2: Lower NIR (810 + 830 nm)
- Channel 3: Mid NIR (850 nm)
- Channel 4: Deep NIR (1064 nm)

Performance Specifications

Irradiance
- 98.87 mW/cm² at 6 inches
- 93.25 mW/cm² at 12 inches
- 81.89 mW/cm² at 24 inches
- 61.59 mW/cm² at 36 inches
Beam Angle: 16.9°
Pulsing: 0 to 5000 Hertz
Flicker: Imperceptible
EMF: 0.0 μT at 6 inches onward

Operation & Modes

Controls: Touch Screen and Remote Control
Quick Access Modes (5): Face & Skin, Pain & Inflammation, Weight Loss, Brain Health, Hair
Advanced Modes: Full Spectrum and Custom Mode
- Custom Mode: Adjust intensity, timing, and pulse frequency (including Nogier) on each channel.

LED Configuration

Number of LEDs: 72
LED Type: 3535 Single-Chip
LED Wattage: 5 watts
LED Lifespan: >100,000 Hours

Build & Material

Material: Iron
Panel Size: 11.8 x 11.4 x 2.4 in (300 x 290 x 62 mm)
Panel Weight: 8.8 lb (4 kg)
Shipped Box Dimensions: 14 x 14 x 7 in (355 x 355 x 180 mm)
Shipped Weight: 12.1 lb (5.5 kg)

Certifications

FDA Registered
CE and RoHS Certified

Electrical

Voltage: AC 100-240 V
Power Consumption: 120 Watts (typical)

What's in the box?

1 x Helio Spark Panel with Tabletop Stand
1 x Remote Control
1 x Power Cable
1 x Protective Reading Glasses (included free)
1 x Blackout Goggles (included free)
1 x User Manual

Warranty, Shipping and Returns

60-Day Returns: Not the right fit? Send it back, no restocking fee.
3-Year Warranty: Covers all manufacturing defects.
Free USA Shipping: Arrives in 4-7 business days.
Delivery Dates: Some panels ship on a later date. You see the date on this page and at checkout, before you pay.

Featured In

Healthy aging, brighter days

Built for Longevity

Only Helio Cure Delivers the Essential Cellular Support Our Bodies Need as We Age. Six targeted wavelengths with industry leading penetration depth: sharper brain function, glowing skin, stronger muscles, and mobile joints.

Backed by research. Designed for real life.

Brain & Cognitive Aging

810 / 1064 nm

Studied for healthy cognition, focus and neural support.

Skin & Healthy Aging

630 / 660 nm

Studied for collagen production, skin tone and radiance.

Muscle & Recovery

810 / 830 / 850 nm

Supports muscle performance, recovery and healthy aging mobility.

Joints & Mobility

810 / 830 / 850 / 1064 nm

Studied for joint comfort, mobility and long-term active living.

The Helio Cure spectrum

61% NIR + Deep NIR

The wavelengths your body needs most for healthy aging.

6 Wavelengths
Real impact

39% Red Light(630 / 660 nm)
42% Near-Infrared(810 / 830 / 850 nm)
19% Deep NIR(1064 nm)

More life in your years. Science for what's next.

0% blue lightGentle, eye-safe therapy

6 therapeutic wavelengths630 • 660 • 810 • 830 • 850 • 1064 nm

Up to 1064 nmOne of the deepest spectra available

Age gracefullySupport your body deserves, year after year

What Makes Helio Spark Different

Our smallest panel, for one area at a time, a knee, a shoulder, face or scalp, 10 to 20 minutes each.

5 Pre-Set Modes for the most common goals, one touch each. Full Spectrum for everything at once.

Face & Skin · Pain & Inflammation · Weight Loss · Brain Health · Hair · Full Spectrum

6 Most Effective Wavelengths provide deepest healing and maximum therapeutic benefit.

630 · 660 · 810 · 830 · 850 · 1064 nm

61%+ Deep-Penetrating LEDs deliver a complete dose at every depth in every session.

38.88% Red · 41.66% Near-Infrared · 19.44% Deep NIR

300+ mW/cm² at Source packs the power for a complete session in under 20 minutes.

98.87 mW/cm² at 6 inches · Verified by LightLab International

Safe & Tested for regular use. Performance tested by an accredited 3rd party US lab.

FDA Registered Class II Medical Device · CE & RoHS · Zero EMF at use distance · Imperceptible Flicker

No Blue Light protects your eyes and your sleep. It helps mainly with acne at the skin level, and we built for deeper.

16.9° Focused Beam Angle and Honeycomb Design send the light deep into your body and spread it evenly, so the whole area you treat gets the same dose.

Set Custom Mode your way, or as your doctor recommends.

Intensity and pulse per channel · Session time

No App, No Tracking means we never collect or share your data.

Built to Last with an iron housing and 100,000+ hour LEDs, so it holds up to years of regular sessions.

Easy to Use with touch and remote control. Run every session from the panel or from where you are.

Tabletop Stand lets you set the height on any table or desk, then pack the panel in a bag when you travel.

Independent · Third-Party · Lab Tested by LightLab International. See the test report →

Get Free Guidance for Your Goals

Five preset modes cover the most common goals. Tell us yours and we recommend the mode, session length and weekly schedule, so you never have to guess.

Ask Us

Response within 24 hours.

How to Use Helio Spark

Plug in. Pick your mode. Start therapy.

Step 1

Set Up

Place on a stable surface. Plug in, power on, put on eye protection.

Step 2

Pick Your Mode

Use the touchscreen or remote to select one of 5 precision modes, full spectrum, or custom.

Step 3

Start Your Session

Sit 1-3 feet away. 10-20 minutes per session, 5 days a week.

Try Helio Cure Risk-Free

This is an investment. We want you to make it confidently.

60-Day Trial

Use it. If it's not right, send it back. No questions.

3-Year Warranty

Built to last. We stand behind it with a 3-year warranty.

Free USA Shipping

No hidden costs. No extra fees. Free across the US.

HSA/FSA Eligible

Pay through TrueMed with your health savings account.

Frequently Asked Questions

How quickly will I see results?

Give it 2 to 4 weeks of consistent use before you judge anything, and 8 to 12 weeks for a fair trial. Everyone responds differently, which is why you have 60 days to decide.

What areas can Helio Spark cover?

Helio Spark covers targeted areas such as the face, scalp, joints or specific muscle groups.

Can I treat multiple areas in one session?

Yes. Reposition the panel between areas during a single session. Each area needs 10-20 minutes of direct exposure.

Is Helio Spark portable?

Yes. Helio Spark is compact and lightweight with a tabletop stand. It is designed for home use and travel.

Is Helio Spark safe?

Yes. All Helio Cure devices are FDA-registered and CE/RoHS certified. Independent third-party lab testing by LightLab International. 0.0 μT EMF at use distance. Imperceptible flicker. Protective eyewear included.
